IALA Certified Self Contained Solar Marine Lantern For Beacon Fixed Structures

Name: IALA Certified Self Contained Solar Marine Lantern For Beacon Fixed Structures
Brand: Chengdu Dixin Technology Co. , Ltd.
SKU: DX-LED-02-G
Availability: InStock

Product Details

Place of Origin: China Chengdu

Brand Name: DIXIN

Certification: ROHS,CE

Model Number: DX-LED-02-G

Payment & Shipping Terms

Minimum Order Quantity: 1 PC

Price: Contact Us

Packaging Details: Carton

Delivery Time: Contact Us

Payment Terms: T/T

Supply Ability: 5000pcs/Month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      Fixed Structures Solar Marine Lantern, Beacon Solar Marine Lantern, IALA Certified Solar Marine Lantern


Product Name:	Fixed Solar Powered LED Lantern	Flash Syncronization:	GPS Synchronized Flash
Solar Output:	4X7W	Warranty:	3 Years
IP Rate:	IP68	Color:	Red/Green/Yellow/Blue/White/Yellow And Blue

Product Name:	Fixed Solar Powered LED Lantern
Flash Syncronization:	GPS Synchronized Flash
Solar Output:	4X7W
Warranty:	3 Years
IP Rate:	IP68
Color:	Red/Green/Yellow/Blue/White/Yellow And Blue

Description

IALA Certified Self Contained Solar Marine Lantern For Beacon Fixed Structures

IALA Certified Self Contained Solar Marine Lantern For Beacon Fixed Structures

Product Overviews:

Our Fixed Self-Contained Solar Marine Lantern delivers reliable illumination with an impressive 7 NM range,

making it ideal for beacon installations, light towers, and other fixed structure applications.

Featuring a self-contained LED light source, an integrated GPS module, and four high-efficiency solar panels,

this lantern ensures optimal energy utilization. Its robust,

weather-resistant design guarantees long-lasting performance in even the harshest marine environments.

Features and benefits:

Sturdy & Resistant: Fiberglass housing ensures UV resistance, shockproof and corrosion-proof durability.
Waterproof Protection: IP68-rated for harsh marine environments with a 7 NM optical range.
Self-Contained System: Integrated LED light, battery, and four 4x7W solar panels maximize energy efficiency.
Bright & Efficient: High-intensity LED array delivers bright, energy-saving illumination.
Long-lasting Power: Battery autonomy of up to 25 days without solar charging.
Automatic Operation: Digital sensor for light control with GPS synchronization.
Customizable Options: Over 256 flash patterns and six IALA-approved colors.
Remote Management: Program and monitor via PC or 433 remote control.
Bird Protection: Integrated deterrent minimizes disruptions.
Standards-Compliant: Built to IALA recommendations for dependable navigation.

Specifications:

Phisical Spec	Lens material	Acrylic
	Body material	Fiberglass
	Operating temperature range	-35°C to +°65C
	Humidity	0~100%
	IP Rating	IP68
	Size (mm )	240X240X455mm
	Life time	10 years(excluding battery)
	Weight	≤11KGS
Battery Spec	Battery type	Lithium iron phosphate
	Battery nominal voltage	12.8V
	Battery autonomy	25 days
	Battery capacity	384Wh/512Wh/665Wh
	Recharging power	Typical 400 mA
	Standby power	3mA current
	Operating Voltage	DC 10V—14.6V
	Battery life	5 years
Solar Spec	Solar module type	Mono crystalline Silicon
Solar Spec	Solar output	4X7W
Optical Spec	Light Source	LEDs
	Light color	Red/Green/Yellow/Blue/White/Yellow and blue
	Visible Range	3-7NM available
	Horizontal Output(degrees)	360°
	Vertical Divergence(degrees)	≥2.5°
	Light value	256 adjustable
	Brightness	adjustable in units of 1%
	Operation Mode	Built-in sensor, dark and day adjust automatically
	LED Life Experience(hours)	>100,000H

Dimension Drawing:

IALA Certified Self Contained Solar Marine Lantern For Beacon Fixed Structures 0

Applications:

Quality Control:

ISO9001, 14001, 45001

About Us:

Established in 2003 and officially registered in 2018,
Chengdu Dixin Technology Co., Ltd. is located in Chengdu, Sichuan, China.

We specialize in the research and development, production, sales, technical support,
and system engineering construction of marine electronic products.
Our dedication to innovation is reflected in our portfolio of over 20 national patents,
including new utility patents, appearance patents, and software copyrights.

Our Products include AIS AtoN (Aids to Navigation), stand alone and self contained AIS marine lantern,
AIS base station, marine antenna, Ultrasonic Anemometer, intelligent energy management systems, etc.

IALA Certified Self Contained Solar Marine Lantern For Beacon Fixed Structures 4
